Maximum shrinkage capacity: Outer diameter 108
Maximum processing tube thickness: with a diameter of 76*150mm long tip can be processed to a thickness of 8.0mm.
With a diameter of 76*360mm long tip can be processed to a thickness of 5.0mm.
With 108*200mm long tip can be processed to a thickness of 4.0mm.
Mold length: mm 400
Spindle motor power: kw 15
Spindle speed: rpm 248
Voltage: 38050HZ
Molding time: seconds 7-30
Weight: T 3
Feed: do not feed multiple times
Feeding accuracy: mm plus or minus 0.1
Volume size: mm 3000*1800*1650
Maximum taper: mm 380
High frequency heating
Model number HD-100
Input voltage: 380V
Output power: 90KW
Oscillation frequency: 30-100KHZ
Cooling water pressure: 0.3MPa
Water temperature: < 40°
Main and auxiliary machine weight: 40KG/30KG
