applied range
Mainly used in all kinds of hardware products, square pipes, round pipes, angle irons and metal profiles, mainly used in the production of stainless steel furniture, wheelchairs, automobile industry, petroleum machinery, wrought iron processing, zinc-steel guardrails, agricultural tools, pig-raising equipment and stainless steel decoration engineering, and other hardware products, to improve work efficiency.
This machine can cut pipes, fire escape pipes, door bolt pipes, pig beds, doors and windows, water sprinklers, etc. As long as pipe products are needed, this machine can cut. In the past, cutting machines were used to cut, and there were sparks and uneven cuts. The cuts made by this machine were straight. Automatic cutting, automatic cutting after cutting to length, the speed is fast, and labor is saved a lot.
Equipment parameters
name | Automatic feeding pipe cutter |
Processing range | φ20-φ50mm |
Machinable wall thickness | Below 2.5mm |
Main motor | 1.5KW |
Feeding motor | 0.37KW |
outline dimension | 1030*850*1150mm |
weight | 200KG |
